Ez Dispensing

You control the flow of material with the PadEZ® system by choosing: push-button manual control, foot pedal operation, batching mode, or our Cut and Hold electronic dispensing system which automatically creates a pad and then pauses until you’re ready for the next one.

Ez Paper Handling

The PadEZ® system changes paper handling with several key innovations:

• Roll Placement — The system can be loaded from the front or the rear.
• Auto Loading — Our patented Auto-Loading technology uses sensors to jog the material into position,
• Adjustable pad Width — Allows the operator to adjust the width to accommodate a variety of product demand for increased protection.

Ez Control Panel

The PadEZ® system features the debut of our SmartStation control panel, and completely redesigned and intuitive interface that significantly reduces operator training.

Ez Positioning

The PadEZ® system can be configured to stand upright, online, or horizontally for under-the-table placements.

• Produces up to 150 custom-length paper pads per minute
• Operates in manual, auto-repeat, and programmable sequence modes for flexibility
• Bottom-loading design allows for fast material changeovers
• Delivers excellent protective cushioning for wrapping, blocking, and bracing
• Available in 100% recyclable kraft or white paper, reducing packaging waste
• Ideal for fulfillment centers, automotive, and electronics packaging

Dimensions:

34″ x 29″ x 59″ (86 cm x 73 cm x 150 cm)

Weight:

340 lbs / 154 kg

Paper Width:

29″ (73.5 cm), available in 1 & 2 ply

Production Speed:

Up to 150 pads per minute

Operation Modes:

Manual, Auto-repeat, and Programmable sequence

Material Options:

Kraft paper (100% recycled), white paper (virgin pulp)
